The Foil Half Bridge Strain Gauge (FB-A) is a high-precision instrument strain gauge manufactured by HBSENSOR (Haibo Sensor), a specialized producer of strain measurement solutions. HBSENSOR (Haibo Sensor) is a professional sensor manufacturer focused on strain gauges, load cells, and force measurement systems. The company provides reliable solutions for industries measuring analysis testing.
Type: FB-a half-bridge type of strain gauge for measuring strain in one direction.
Applications: Ideal for load cells, structural testing, material research, and industrial equipment monitoring.
Construction:
Foil Material: Constantan or nickel-chromium alloy for stable resistance characteristics.
Backing: Flexible polyimide substrate for durability and adhesion.
Resistance: Standard 120 120Ω or 2000 Ω (depending on model).
Gauge Factor: ~2.0–2.2 (typical for metallic foil gauges).
Temperature Compensation: Optimized for compatibility with 11 = Alloy Steel, 16 = Stainless Steel, 23 = Aluminium Alloy, 27 = Magnesium Alloy, M23 = Aluminium Alloy
1. FB-A is a half-bridge foil strain gauge sensor.
Load Cells (beam-type, bending applications).
Stress Analysis (unidirectional force testing in materials).
Structural Monitoring (e.g., axial strain in bridges, trusses)
Wire Length: Electric Cables, Silver, Enameled Wires
Strain Gauge Outer Size.
ODM/OEM.
Package.
