Sensor range
HBTL611N is a micro load cell and popular designed for measuring weights up to 100 grams and outer size 80mm in length, These load cells are typically designed for high sensitivity and accuracy.
Low Capacity: Accurately measures weights up 1-50kg
Compact Size: Dimensions of approximately 80mm,suitable for integration in space-constrained applications.
Aluminum alloy construction: Raw materials can be customized according to customer requirements
Low Power Consumption: Designed for efficient power use, making it suitable for battery-operated devices.
IP65 Protection Rating: The load cell is designed with an IP65 rating. Easy installation
Weighing Scales: Used in portable or compact digital scales for precise weight measurement,Fish Scales,Kitchen Scales,Smart Kitchen Household Products.
Medical Equipment: Ideal for applications in healthcare such as patient scales or devices requiring accurate weight readings.
Industrial Testing: Used in situations requiring precise measurements in product testing or quality control processes.
Consumer Products: Often integrated into smart kitchen scales or fitness devices for monitoring food portions or body weight.
Vending machine:Micro coffee vending machine, snack vending machine, intelligent micro medical storage cabinet.
Wire Length.
Connect Connector, Example: JST or XX Brand Connetctor.
ODM/OEM
Weighing Accessories
Pacakge
|
Sensor range
|
1kg ～ 50kg
|
|
Output sensitivity
|
1.0±0.15 mV/V
|
|
Linear error
|
±0.05% FS
|
|
Lag error
|
±0.05% FS
|
|
Off center load error
|
±0.1% FS
|
|
Zero output
|
±0.1 mV/V
|
|
Input impedance
|
1000±10Ω
|
|
Output impedance
|
1000±10Ω
|
|
Influence of zero temperature
|
±0.1% FS/10℃
|
|
Sensitivity temperature effect
|
±0.05% FS/10℃
|
|
Reference excitation voltage
|
3VDC ~ 10VDC
|
|
insulation resistance
|
≥2000MΩ
|
|
working temperature
|
0℃ ~ +40 ℃
|
|
Storage temperature
|
-10℃ ~ +60 ℃
|
|
Safe overload range
|
120%
|
|
Limit overload range
|
150%
|
|
Material Science
|
铝合金/Aluminum Alloy
|
|
Protection level
|
IP65
|
|
External dimension of sensor
|
80*12.7*12.7
|
|
Mounting hole size
|
4-Φ7.4
|
As the best quality load cell sensor products manufacturer, we can provide professional solutions for any custom request. Please feel free to contact us now and we will contact you soonest.
